Application situation:
Standby Generators for power outagesOn-site generators for the construction Industry
Mobile generators for events and catering
Portable Generators for Camping and outdoor activities
Batteries for clean, silent, mains power anywhere and everywhere
What is a portable power station?
A portable power station is a generator powered by a rechargeable battery. Equipped with an AC outlet, DC carport, and USB charging ports,
they can keep all your gear charged, from smartphones, tablets, laptops, to CPAPs and small devices, like a fan, mini coolers, electric blankets, etc.
How does a portable power station work?
In fact, it is a DC to AC inverter that increases the DC voltage and then changes it to AC before sending it out to power a device, like your laptop and TV.
The DC input port collects and stores electricity / energy from an AC outlet or solar panel and outputs via built-in USB ports, DC carport or AC outlet
| Model |
LF-SG-3000W |
|
INVERTER OUTPUT &INPUT |
|
|
Rated Power |
3000W |
|
Peak Power |
9000W |
|
Output Waveform |
Pure sine wave |
|
Output Voltage |
10/120VAC（L-N) & 220/230/240VAC(L-N-L)±10RMS |
|
Input Frequency Range |
45Hz-65Hz |
|
Output Frequency Range |
50Hz/60Hz ±10% |
|
Conversion Time |
≤5ms |
|
Cooling Method |
Intelligent fan cooling, ≤42℃ fan rotates slowly, ≥45℃ fan rotates fast |
|
AC INPUT&OUTPUT |
|
|
Input Voltage Range |
110/120VAC（L-N) & 220/230/240VAC(L-N-L) |
|
Output Voltage Range |
85-138VAC(AC:110) 170-275VAC(AC:220) |
|
Output Frequency Range |
Automatic tracking |
|
AC Charging Current |
15A |
|
Max solar charging current |
30A,40A,50A,60A,80A |
|
Max PV input power |
48V-30A:1440W,48V-50A:2400W,48V-60A:2880W,48V-80A3840W,48V-100A:4800W,48V-120A:5760W |
|
PV array MPPT voltage range |
48V:72V-150V |
|
Peak conversion efficiency |
>99% |
|
BATTERY |
|
|
Battery type |
LiFePO4 |
|
DC Voltage |
48VDC |
|
Battery capacity |
3000WH |
|
Battery Under Voltage Alarm |
40 VDC±0.3V |
|
Battery Over Voltage Alarm |
60 VDC±0.3V |
|
Battery Under Voltage Protection |
42 VDC±0.3V |
|
Battery Over Voltage Protection |
66VDC±0.3V |
Packing
