Feature:
Good high temperature performance
Safe Lithium Iron Phosphate Technology
High energy density and conversion efficiency
Life Span: 2000 cycle times
Environmental Friendly, without any heavy metals
Complete with Battery Management System built-in
Can use AC and solar chargers for this system
Low self discharge rate
Easy installation, can be in standard cabinet or be wall-mounted
Built-in automatic protectionfor over-charge, over-discharge&over-temperature conditions
High energy density 120-130kwh/kg,evenhigh discharge rate , while maintaining high energy capacity.
Increased Flexibility : Modular design enables deployment
Good High Rate Discharging and Excellent Stability
Intelligent chip design, excellent battery's storage capacity
Applications：
The solar energy battery is applicable for industrial , commercial or residential purposes
Battery Modules or Units are connected from Wh up to Mwh for renewable energy system
Energy Storage System
Solar Energy Storage
Solar Street Lighting
Electric Vehicle ( EV)
Medical
Telecom
Robotic
UPS
|
Item |
Specification |
|
Type |
lithium battery |
|
Voltage |
48V |
|
Rated capacity |
100Ah (0.2C/25°C) (Min:98Ah) |
|
Energy |
4800wh |
|
Operating voltage range |
42V- 58.4V (Typical:51.2V) |
|
Charging voltage |
56.0V±1.0V |
|
Discharge cut-off voltage |
42V±2.0V |
|
Charging current |
20A |
|
Charging current(Max.) |
30A |
|
Continuous Current |
50A |
|
Discharge current(Max.) |
100A |
|
Months Self Discharge |
≤3.5% |
